1. Compact and lightweight to be carried around: designed to lighten the burden of the film industry, the VB series is approximately 30% smaller than traditional V-mount batteries!
2. Intelligent BMS chip for efficient and safe use: a built-in highly integrated BMS chip takes up less space while supporting varied fast-charging protocols and bi-directional 65W (Max) USB-C PD fast charging!
3. Various interfaces for high compatibility: compatible with camera/camcorder/monitor/wireless transmitter/video light, etc.
4. Practical OLED display for precise control: keeps track of the battery's working status at all times!
5. Premium Li-battery with guaranteed quality and safety: built-in high-capacity premium Li-battery, a double guarantee of quality and performance!
In the Box:
VB99 mini V Mount Battery × 1
Smallrig Custom Sticker Set × 1
User Manual × 1
Parameters：
|
Items |
Parameters |
|
Material |
Fireproof PC |
|
Capacity |
14.8V 6.7Ah 99Wh |
|
Rated Power |
Discharge: 99W Charge: 65W |
|
V Mount / D-TAP Input |
8A (Max) |
|
V Mount / D-TAP Output |
14.8V / 14A (Max) |
|
USB-A Output QC2.0 / QC3.0 / AFC / FCP / SCP / DCP-1.5A / APPLE-2.4A |
QC2.0 / AFC / FCP: 5V / 3A, 9V / 3A, 12V /2A QC3.0: 4.2-9V / 3A, 9-12V / 2A SCP: 4.5V / 5A, 5V / 4.5A DCP-1.5A: 5V / 1.5A APPLE-2.4A: 5V / 2.4A |
|
USB-C Input / Output Input 65W (Max) Output 65W (Max) PD3.0 / QC2.0 / QC3.0 / PPS / AFC / FCP / SCP / DCP-1.5A / APPLE-2.4A |
PD3.0: 5V / 3A, 9V / 3A, 12V / 3A, 15V / 3A, 20V / 3.25A QC2.0 / AFC / FCP: 5V / 3A, 9V / 3A, 12V / 2A QC3.0: 4.2-9V / 2A, 9-12V / 2A SCP: 4.5V / 5A, 5V / 4.5A DCP-1.5A: 5V / 1.5A PPS: 3.3-21V / 3A APPLE-2.4A: 5V / 2.4A |
|
DC1 Output |
8V / Max3A |
|
DC2 Output |
12V/Max3A |
|
Cutoff Voltage |
11V |
|
Optional Charging Method |
16.8V D-TAP charger, USB-C charger such as GaN charger with PD fast charging tech (up to 65W) |
|
Product Dimensions |
107.0 × 73.0 × 53.0 mm |
|
Net Weight |
550 g ±10 g |
|
Package Dimensions |
147.0 × 114.0 × 75.0 mm |
|
Gross Weight |
